15 Parameter reference
15.2 Parameter list | C00317
526
Lenze · 8400 protec StateLine · Reference manual · DMS 4.2 EN · 03/2013 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00317
C00320
C00321
C00322
Parameter | Name:
C00317 | WatchdogTimeMax
Data type: UNSIGNED_16
Index: 24258
d
= 5EC2
h
This code is for device-internal use only and must not be written to by the user!
Parameter | Name:
C00320 | Debug information
Data type: UNSIGNED_32
Index: 24255
d
= 5EBF
h
This code is for device-internal use only and must not be written to by the user!
Parameter | Name:
C00321 | Main program runtime
Data type: UNSIGNED_16
Index: 24254
d
= 5EBE
h
Display of the current and the maximum runtime of the main program in the controller
Setting range
(min. value | unit | max. value)
0 ms 65535
Subcodes Lenze setting Info
C00321/1 0 ms Curr. runtime of main program
C00321/2 0 ms Max. runtime of main program
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00322 | Transmission mode CAN TxPDOs
Data type: UNSIGNED_8
Index: 24253
d
= 5EBD
h
TPDO transmission type according to DS301 V4.02
• The following transmission modes are supported:
• 0: Synchronous and acyclic
• 1 ... 240: Synchronous and cyclic
• 252: Synchronous - RTR only
• 253: Asynchronous - RTR only
• 254: Asynchronous - manufacturer-specific
• 255: Asynchronous - device-profile specific
• The basic setting for all PDOs is "Asynchronous - manufacturer-specific" (254).
• Illustration of the CANopen objects I-1800/2 ... I-1802/2 (see DS301 V4.02).
 "CAN on board" system bus
Setting range (min. value | unit | max. value)
0 255
Subcodes Lenze setting Info
C00322/1 254 Transmission mode CAN1 OUT
C00322/2 254 Transmission mode CAN2 OUT
C00322/3 254 Transmission mode CAN3 OUT
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
