Lenze · 8400 protec StateLine · Reference manual · DMS 4.2 EN · 03/2013 · TD05
243
7 Technology applications
7.2 TA "Actuating drive speed"
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Process controller
• In the Lenze setting, the process controller is deactivated.
• The activation is executed by selecting the operating mode in C00242 .
• For a detailed functional description see FB L_PCTRL .
bPIDEnableInfluenceRamp
BOOL
Activate ramp for influencing factor
FALSE Influencing factor of the PID controller is ramped down to "0".
TRUE Influencing factor of the PID controller is ramped up to the value
nPIDInfluence_a.
bPIDIOff
BOOL
Switch off the I-component of the process controller
• In conjunction with the operating mode set in C00242
(Lenze setting: "Off").
TRUE I-component of the process controller is switched off.
nPIDVpAdapt_a
INT
Adaptation of gain Vp set in C00222 in percent
• Scaling: 16384 ≡ 100 %
• Internal limitation to ± 199.99 %
• Changes can be done online.
nPIDSetValue_a
INT
Sensor and process setpoint for operating modes 2, 4 and 5
• Scaling: 16384 ≡ 100 %
• Internal limitation to ± 199.99 %
nPIDActValue_a
INT
Speed or actual sensor value (actual process value)
• Offset and gain for this input signal can be set in C00698 and C00672 .
• Scaling: 16384 ≡ 100 %
• Internal limitation to ± 199.99 %
nPIDInfluence_a
INT
Limitation of the influencing factor in percent
• The influence factor of the PID controller can be limited to a certain value (-
199.99% ... + 199.99%) via nPIDInfluence_a.
• Scaling: 16384 ≡ 100 %
• Internal limitation to ± 199.99 %
MCK basic functions
bMBRKRelease
BOOL
Holding brake control : Release/apply brake
• In conjunction with the operating mode selected in C02580
(Lenze setting: "Brake control off").
FALSE Apply brake.
• During automatic operation, the internal brake logic controls the
brake.
TRUE Release brake.
• During automatic operation, the internal brake logic is
deactivated and the brake is released. If the brake control has
inhibited the controller, this inhibit is deactivated again.
bManJogPos
bManJogNeg
BOOL
reserved (inputs are not interconnected on the application level)
GP: GeneralPurpose
The following inputs are interconnected with logic/arithmetic functions on application level for free usage.
 "GeneralPurpose" functions
nGPAnalogSwitchIn1_a
nGPAnalogSwitchIn2_a
INT
Analog switch : Input signals
• The input signal selected via the selection input bGPAnalogSwitchSet is output at
output nGPAnalogSwitchOut_a.
bGPAnalogSwitchSet
BOOL
Analog switch : Selection input
FALSE nGPAnalogSwitchOut_a = nGPAnalogSwitchIn1_a
TRUE nGPAnalogSwitchOut_a = nGPAnalogSwitchIn2_a
nGPArithmetikIn1_a
nGPArithmetikIn2_a
INT
Arithmetic : Input signals
• The arithmetic function is selected in C00338 .
• The result is output at output nGPArithmetikOut_a.
Identifier
Data type
Information/possible settings
