Function library
17.1
Function blocks
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Related topics:
Overview of system blocks available
20 μs
... is a PID controller and can be used for various control tasks.
1 μs
... filters and delays analog signals.
3 μs
... links a selected direction of rotation to the QSP function with wire-
break protection.
15 μs
... serves to output analog output signals of other FBs, SBs or LAs.
3 μs
... serves to output binary output signals of other FBs, SBs or LAs.
2 μs
... decodes the control word of the integrated safety system into
individual binary control signals for further processing in the application.
2 μs
... decodes the status word of the integrated safety system into
individual binary status signals for further processing in the application.
2 μs
... decodes the I/O status word of the integrated safety system into
individual binary status signals for further processing in the application.
3 μs
... evaluates digital signal edges and converts them into timed pulses.
Function block
Runtime Function
