15 Parameter reference
15.2 Parameter list | C00495
558
Lenze · 8400 protec StateLine · Reference manual · DMS 4.2 EN · 03/2013 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00495
C00496
C00497
Parameter | Name:
C00495 | Speed sensor selection
Data type: UNSIGNED_8
Index: 24080
d
= 5E10
h
Selection of the feedback system for the actual speed for motor control and display
 Encoder/feedback system
Selection list (Lenze setting printed in bold) Info
0 No sensor No sensor available for the actual speed detection
1 Sensor signal FreqIn12 Speed sensor signal is fed via the digital DI1 and DI2
inputs
2 Encoder signal FreqIn56 Speed sensor signal is fed via the digital DI5 and DI6
inputs
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00496 | Encoder evaluation method DigIn12
Data type: UNSIGNED_8
Index: 24079
d
= 5E0F
h
 Encoder/feedback system
Selection list (Lenze setting printed in bold) Info
0 High-resolution encoders High-precision procedure for high-resolution encoders
(>=512 increments)
1 Low-resolution encoder (StateLine) High-precision procedure for low-resolution encoders
(<=128 increments)
2 Comb. encoder procedure Combination of the first two procedures as a function of
the speed (recommended procedure)
3 EdgeCounting analysis Simple edge counting procedure with adjustable
scanning time ( C00425 )
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00497 | Nact filter time constant
Data type: UNSIGNED_16
Index: 24078
d
= 5E0E
h
 Encoder/feedback system
Setting range
(min. value | unit | max. value)
0.0 ms 500.0
Subcodes Lenze setting Info
C00497/1 1.0 ms Encoder filter time FreqIn12
C00497/2 1.0 ms Encoder filter time FreqIn56
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 10
