Lenze · 8400 protec StateLine · Reference manual · DMS 4.2 EN · 03/2013 · TD05
493
15
Parameter reference
15.2
Parameter list | C00101
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00101
C00103
C00105
C00106
Parameter | Name:
C00101 | Add. accel. time x
Data type: UNSIGNED_32
Index: 24474
d
= 5F9A
h
: FB: Additional acceleration times for the main setpoint
• The additional acceleration times set here can be selected via the binary inputs bTI1 ... bTI8 of the
FB.
Setting range
(min. value | unit | max. value)
0.000
s
999.999
Subcodes
Lenze setting
Info
C00101/1
0.000 s
Add. accel. time 1 ... 15
C00101/...
C00101/15
Read access Write access CINH PLC STOP No transfer COM MOT
Scaling factor: 1000
Parameter | Name:
C00103 | Add. decel. time x
Data type: UNSIGNED_32
Index: 24472
d
= 5F98
h
FB: Additional deceleration times for the main setpoint
• The additional deceleration times set here can be selected via the binary inputs bTI1 ... bTI8 of the
FB.
Setting range
(min. value | unit | max. value)
0.000
s
999.999
Subcodes
Lenze setting
Info
C00103/1
0.000 s
Add. decel. time 1 ... 15
C00103/...
C00103/15
Read access Write access CINH PLC STOP No transfer COM MOT
Scaling factor: 1000
Parameter | Name:
C00105 | Decel. time - quick stop
Data type: UNSIGNED_32
Index: 24470
d
= 5F96
h
The set deceleration time determines the ramp slope at quick stop
Setting range
(min. value | unit | max. value)
Lenze setting
0.000
s
999.900 2.000 s
Read access Write access CINH PLC STOP No transfer COM MOT
Scaling factor: 1000
Parameter | Name:
C00106 | Auto DCB: Hold time
Data type: UNSIGNED_32
Index: 24469
d
= 5F95
h
Hold time of the automatic DC injection brake
• The DC injection brake is applied for the time set here if the value falls below the speed setpoint set in
Setting range
(min. value | unit | max. value)
Lenze setting
0.000
s
999.000 0.500 s
Read access Write access CINH PLC STOP No transfer COM MOT
Scaling factor: 1000
