14 Parameter change-over
14.2 Configuring the list using the »Engineer« parameterisation dialog
462
Lenze · 8400 protec StateLine · Reference manual · DMS 4.2 EN · 03/2013 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
3. Click on the button in order to add the highlighted parameters to the WriteParamList
on the right-hand side.
• With the and buttons, you can alter the sequence of parameters in the
WriteParamList.
To remove parameters from the WriteParamList, proceed as follows:
• Highlight the parameter/parameters in the WriteParamList that is/are to be removed
from the WriteParamList.
• Click on the button to remove the highlighted parameters from the WriteParamList.
4. Click on the OK button to accept the configuration and close the dialog box.
• You can call the configuration dialog again at any time in order to change or expand the
WriteParamList retrospectively.
Entering values
After composing the list, you can directly enter the desired parameter values into the input fields
(columns 1st value ... 4th value).
If you place the cursor in an input field, the permitted value range for the corresponding parameter
is shown under the table.
Copying values
All the settings of a value set can be copied to another value set.

To copy values, proceed as follows:
1. Click on the Copy values button.
• The Copy values dialog box is displayed:
2. Select Source and Target.
3. Click on button in order to copy the values from Source to target.
