15 Parameter reference
15.2 Parameter list | C00440
546
Lenze · 8400 protec StateLine · Reference manual · DMS 4.2 EN · 03/2013 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00440
C00443
Parameter | Name:
C00440 | LS_AnalogIn1: PT1 time constant
Data type: UNSIGNED_16
Index: 24135
d
= 5E47
h
PT1 time constant (S-ramp time) for the analog input
 Analog terminals
Setting range (min. value | unit | max. value)
0 ms 1000
Subcodes Lenze setting Info
C00440/1 10 ms PT1 rounding AnalogIn1
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00443 | DIx: Level
Data type: UNSIGNED_16
Index: 24132
d
= 5E44
h
Bit coded display of the level of the digital inputs
 Digital terminals
Display area (min. hex value | max. hex value)
0x0000 0xFFFF
Value is bit-coded: Info
Bit 0 DI1 Bit set = HIGH level
Bit 1 DI2
Bit 2 DI3
Bit 3 DI4
Bit 4 DI5
Bit 5 DI6
Bit 6 Reserved
Bit 7 Reserved
Bit 8 Reserved
Bit 9 Reserved
Bit 10 Reserved
Bit 11 Manually
Bit 12 Right
Bit 13 Left
Bit 14 Mains
Bit 15 CINH
Subcodes Info
C00443/1 DIx: Terminal level
C00443/2 DIx: Output level
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT
