13 Drive-based safety
13.1 Selection of the safety option
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
13.1 Selection of the safety option
If you insert the 8400 protec StateLine controller via the Insert a component dialog into the Project
view of the »Engineer«, you will be queried in the second dialog step Device modules about the
communication and safety system in the device.

Select the available safety option in the Safety engineering list field in order that the tabs
of the integrated safety system are available in the »Engineer«.

Tip!
The available safety option can also be assigned subsequently to the device in the
»Engineer« any time:
1. In the Project view, select the 8400 protec StateLine controller.
2. Click the icon.
3. Select the available safety option in the Insert device module dialog box.
4. Press Complete to confirm your selection.
13.2 Parameter setting

Note!
Safety-relevant parameters can only be transmitted to the integrated safety system via
safe parameter setting with the »Engineer«.
The parameter set is stored in the memory module and in the integrated safety system
with a unique module ID, which must correspond to the effective safety address in the
integrated safety system.

Detailed information on safe parameter setting of the integrated safety system can be
found in the online documentation "Integrated safety".
