Lenze · 8400 protec StateLine · Reference manual · DMS 4.2 EN · 03/2013 · TD05
433
10 CANopen option
10.11 Implemented CANopen objects | I-1600
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
I-1600
The object I-1600 serves to receive parameter data as RPDO1.
• This object relates to codes C00409/1...4 and C00866/1...4 .
[10-14] Data telegram assignment
IEC 61131 process data words are mapped. Only whole bytes can be mapped (1-byte/mapping
entry).
Related topics:
 RPDO1 | Port block "LP_CanIn1" ( 388)
Index:
I-1600
Name:
RPDO1 mapping parameter
Subindex Default setting Setting range (min. value | unit | max. value) Access Data type
0: Number of mapped application
objects in PDO
0 0 8 rw U8
1 ... 4: Application object 1 ... 4 0 0 4294967295 rw U32
Subindex Meaning
0 Number of mapped objects
1 ... 4 Mapping entries 1 ... 4 for RPDO1
• The 4th mapping entry is used for the statistic mapping. For this, there is no value
available.
8th byte 7th byte 6th byte 5th byte
Data 4 Data 3 Data 2 Data 1
Bit 31 ... bit 16 Bit 15 ... bit 8 Bit 7 ... bit 0
Index Subindex Length
