16 Working with the FB Editor
16.4 Reconfiguring the predefined interconnection
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Context menu for the port block
If you right-click on the header of a port block, a context menu opens via which you can execute the
following functions in addition to the general processing functions (Copy, Insert, Delete):
Related topics
 Deleting objects that are no longer required ( 688)
 Changing connector visibilities ( 689)
 Arranging objects in the drawing area ( 690)
 Creating/deleting connections ( 691)
Command Function
Center Move the visible cutout of the drawing area so that the block is centred.
Connector visibilities... Define visible inputs and outputs of the block.
 Changing connector visibilities ( 689)
Online display format... Adapt the display format of the input and output data of the block
individually for online monitoring.
 Change online display format ( 677)
Parameter... Open the parameter list/parameterisation dialog for the block.
Help Show online help for the block.
