Parameter | Name:
C00671 | L_OffsetGainP_2: Gain
Data type: INTEGER_32
Index: 23904
d
= 5D60
h
FB: Gain as multiplier of the input signal + offset
Setting range
(min. value | unit | max. value)
Lenze setting
-100.0000
100.0000 1.0000
Read access Write access CINH PLC STOP No transfer COM MOT
Scaling factor: 10000
Parameter | Name:
C00672 | L_OffsetGainP_3: Gain
Data type: INTEGER_32
Index: 23903
d
= 5D5F
h
FB: Gain as multiplier of the input signal + offset
Setting range
(min. value | unit | max. value)
Lenze setting
-100.0000
100.0000 1.0000
Read access Write access CINH PLC STOP No transfer COM MOT
Scaling factor: 10000
Parameter | Name:
C00680 | L_Compare_1: Fct.
Data type: UNSIGNED_8
Index: 23895
d
= 5D57
h
FB: Comparison operation
• If the statement of the selected comparison operation is true, the binary bOut output will be set to TRUE.
Selection list
(Lenze setting printed in bold)
1 In1 = In2
2 In1 > In2
3 In1 < In2
4 |In1| = |In2|
5 |In1| > |In2|
6 |In1| < |In2|
Read access Write access CINH PLC STOP No transfer COM MOT
Scaling factor: 1
Parameter | Name:
C00681 | L_Compare_1: Hysteresis
Data type: INTEGER_16
Index: 23894
d
= 5D56
h
FB: Hysteresis for the comparison function selected in
Setting range
(min. value | unit | max. value)
Lenze setting
0.00
%
100.00 0.50 %
Read access Write access CINH PLC STOP No transfer COM MOT
Scaling factor: 100
Parameter | Name:
C00682 | L_Compare_1: Window
Data type: INTEGER_16
Index: 23893
d
= 5D55
h
FB: Window for the comparison function selected in
Setting range
(min. value | unit | max. value)
Lenze setting
0.00
%
100.00 2.00 %
Read access Write access CINH PLC STOP No transfer COM MOT
Scaling factor: 100
