9 Diagnostics & error management
9.10 Error messages of the operating system
368
Lenze · 8400 protec StateLine · Reference manual · DMS 4.2 EN · 03/2013 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
dF10: AutoTrip reset [xx.0145.00035]
dF50: Retain error [xx.0145.00050]
Ck16: Time overflow manual operation [xx.0184.00064]
dH09: EEPROM power section [xx.0400.00009]
dH10: Fan failure [xx.0400.00016]
Response (Lenze setting printed in bold) Setting: C00189 ( Adjustable response)
 0: No Reaction  1: Fault  2: Trouble  3: TroubleQuickStop  4: WarningLocked  5: Warning  6: Information
Cause Remedy
Too frequent auto-trip reset. • Check the error cause that activates the auto-trip
reset.
• Eliminate error cause and reset (acknowledge) error
manually afterwards.
Response (Lenze setting printed in bold)
 0: No Reaction  1: Fault  2: Trouble  3: TroubleQuickStop  4: WarningLocked  5: Warning  6: Information
Cause Remedy
An error has occurred when accessing retain data.
• Either caused by an internal hardware error or by lack
of mains switching after a firmware download.
Mains switching
• Please contact Lenze if the problem occurs again.
Response (Lenze setting printed in bold)
 0: No Reaction  1: Fault  2: Trouble  3: TroubleQuickStop  4: WarningLocked  5: Warning  6: Information
Cause Remedy
PC manual control: The connection monitoring has
tripped.
• The online connection between the PC and the
controller has been interrupted for a longer period of
time than the timeout set in C00464/1 .
• Check communication link between PC and
controller.
• Check voltage supply/function of the controller.
• Adjust the timeout ( C00464/1 ).
Response (Lenze setting printed in bold)
 0: No Reaction  1: Fault  2: Trouble  3: TroubleQuickStop  4: WarningLocked  5: Warning  6: Information
Cause Remedy
Device error Consultation with Lenze required.
Response (Lenze setting printed in bold) Setting: C00566 ( Adjustable response)
 0: No Reaction  1: Fault  2: Trouble  3: TroubleQuickStop  4: WarningLocked  5: Warning  6: Information
Cause Remedy
The device fan has failed.
Possible causes:
• The short-circuit check of the fan connection has
tripped.
• The speed monitoring of the fan has tripped.
• Check the fan for short-circuit.
• Clean the fan.
