15 Parameter reference
15.2 Parameter list | C00385
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00385
C00386
C00400
Parameter | Name:
C00385 | CAN node addr. HeartBeat producer
Data type: UNSIGNED_8
Index: 24190
d
= 5E7E
h
The subcodes represent the nodes to be monitored by heartbeat.
 "CAN on board" system bus: Heartbeat protocol
Setting range (min. value | unit | max. value)
0 127
Subcodes Lenze setting Info
C00385/1 0 CAN node address 1 ... 7
C00385/...
C00385/7
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00386 | HeartBeat-ConsumerTime
Data type: UNSIGNED_16
Index: 24189
d
= 5E7D
h
The subcodes represent the nodes to be monitored by heartbeat.
 "CAN on board" system bus: Heartbeat protocol
Setting range
(min. value | unit | max. value)
0 ms 60000
Subcodes Lenze setting Info
C00386/1 0 ms ConsumerTime HeartBeat Producer 1 ... 7
C00386/...
C00386/7
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00400 | LS_PulseGenerator
Data type: UNSIGNED_16
Index: 24175
d
= 5E6F
h
Time setting of the pulse to be output by the SB LS_PulseGenerator
Setting range (min. value | unit | max. value)
0 ms 60000
Subcodes Lenze setting Info
C00400/1 1000 ms Length of LOW level (break)
C00400/2 1000 ms Length of HIGH level
C00400/3 100 ms From version 06.00.00
Delay time for status signal bFirstCycleDone
• The bFirstCycleDone status signal is set to TRUE when
the first task cycle is complete and the time set here
has expired.
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
