DRRD-12 ... 63
30 Festo – DRRD-12 ... 63-Z6 – 1310b English
12 Technical data
Size 12 16 20 25 32 35 40 50 63
Design Semi-rotary drive with twin pistons
Cushioning at both
ends
P Elastic cushioning, with metal end position –
Y9 Hydraulic shock absorber (soft)
Y10 – Hydraulic shock absorber (hard)
Pneumatic port M5 M5 M5 M5 G1/8 G1/8 G1/8 G1/4 G3/8
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
Note on the operating medium Lubricated operation possible (in which case lubricated
operation will always be required)
Operating pressure P [bar] 3 … 8 –
Y9/Y10 [bar] 2 … 10
Mounting position Any
Swivel angle [°] 180
Setting range on
both sides
P [°] Infinitely adjustable between –100 … +10 –
Setting range on
both sides
1)
Y9/Y10 [°] Infinitely adjustable between –100 … +10
Cushioning angle
(
Z minimum swivel
angle)
P [°] 32 36 45 33 33 36 23 –
Y9/Y10 [°] 48 43 72 79 82 85 56 61 48
Repetition accuracy [°] ≤ 0.03 < 0.05 ≤ 0.03
Ambient temperature [°C] –10 … +60
Torque at 6 bar (theor.) [Nm] 0.8 1.59 2.41 5.15 10.1 15.8 24.1 53.0 112
Max. axial load (static) [kN] 1.4
3)
1.5 2.4 2.4 3.75 6.1 6.1 9.0 11.0
Max. permissible axial and radial
force on drive shaft
Dependent on the distance of the force application point
( www.festo.com/catalogue)
Max. permissible mass
moment of inertia
Depending on the product type
( www.festo.com/catalogue)
End-position adjustment By turning the cushioning components
Note on materials Contains paint-wetting impairment substances (PWIS)
Materials
Housing, cover Anodised aluminum
Shaft, screws, plug and
retaining plate for DRRD-12
Steel
Seals TPE-U (PU), NBR
Product weight
2)
P [kg] 0.38 0.64 0.84 1.35 2.82 4.51 6.07 –
Y9/Y10 [kg] 0.39 0.65 0.88 1.36 2.98 4.78 6.42 11.3 19.1
1) Reduction possible on one side > 100°; observe the cushioning angle as the minimum swivel angle
2) Basic design with internal cushioning, without accessories
3) Pressure load (tensile load: 0.33 kN)
Tab. 9
