Stacking stand installation
Galaxy
® 170 R/170 S CO
2
Incubators
English (EN)
94
13.3.2 Stacking frame kit contents
All of the parts listed for both kits below are included in the Lower and Upper Stacking Frame Kit
(P0628-6270). Check that you have received all of the parts appropriate to the kit you ordered:
Upper Stacking Frame contents: See the Table below.
Lower Stacking Frame contents: See the Table below.
13.4 Instructions for stacking incubators
Kit for Stacking a pre-2000 incubator onto a Galaxy 170
Quantity Part Description
1 Upper stacking plate with foam insulation
4 M6 x 50 mm slotted pan head bolts
4 Foot locking brackets
4 M6 x 12 mm cap head Allen bolts
1 Allen wrench set
2 Incubator feet with M8 nuts
4 Pads for incubator feet
Quantity Part Description
1 Lower stacking frame
2 Swivel castors, each with adjustable stabilizing foot
2 Fixed castors
8 M8 x 20 mm button head bolts with washers (to mount fixed castors)
2 Incubator feet with M8 nuts
4 Pads for incubator feet
1 Wrench to attach castors
1 Allen wrench set
WARNING! Personnel injury and equipment damage!
 Great care should be taken when moving the stacked incubators. Hazards, including
uneven surfaces and obstructions, may cause the stacked assembly to topple, potentially
injuring personnel.
