48
Innova 43 & 43R Incubator Shakers  M1320-0050 Operating manual
5. When the Temperature Offset is set to any value other than 0, the icon
will appear next to ºC in the DISP and SUMM screens.
NOTE:
If you highlight an item, change it, but do not save your selection, after a few
seconds the screen will revert to its previous setting.
Figure 20: Calibrate Screen
CALIBRATE
°C Offset : 0.0
Calspeed : 250
CAL Th 16:22
7.8 Using Calspeed
The Calspeed function, which is set in the CAL screen (see Figure 20 above), is used to
calibrate the speed of the shaking mechanism. Calibrated at the factory, speed does not
need to be recalibrated until a major operating component (e.g., drive belt) is changed.
NOTE:
Prior to calibrating the speed, make sure that the platform is properly secured
to the subplatform, and any flasks present are secured.
When the shaker is running, the CAL screen shows the indicated RPM value. If you wish
to calibrate the speed, set the speed to a value that can be measured— a setpoint of 250
RPM works well. The use of a strobe is recommended for accuracy. If, after measuring
the actual speed, you wish to adjust the indicated value:
1. Click the Control Knob in.
2. Set the new value.
3. Click the Knob in again to save the setting.
4. Turn the shaker
OFF
, wait a few seconds, then turn the shaker back
ON
.
