38
Innova 43 & 43R Incubator Shakers  M1320-0050 Operating manual
On means the light is always on, and Off means the light is always off, unless you
add additional programming.
There is an additional mode for the chamber light:
Auto . In Auto mode, the light
will go on every time you activate the control knob or open the lid. This is the
default mode.
NOTE:
The Lamps screen, shown below, will always indicate Chamber light mode. If
the shaker is not equipped with the optional UV germicidal lamp and/or
photosynthetic growth lamps,
UV Decont
and/or
Growth
will say
None
.
Figure 18: Lamps Screen
LAMPS
Chamber : Auto
UV Decont : Off
Growth : Off
LAMP Th 16:20
To change the mode setting for any of the lamps:
1. Turn the Control Knob to highlight the setting for the lamp of choice, then
click the knob in. The current setting will flash (in the sample screen, we will
use the
Chamber light as an example.
2. Turn the Knob left or right until the desired mode setting appears ( Auto in this
example).
3. Click the Knob in to save the new setting.
NOTE:
If you highlight an item, change it, but do not save your selection, after a few
seconds the screen will revert to its previous setting.
To move out of this screen and into the next:
1. Use the Control Knob to highlight
LAMP , then click the Knob in. LAMP
begins to flash.
