29
New Brunswick Operating manual
Figure 12c: RH Sensor Connection
M1282-7002
1 Board inside the service compartment
Figure 12d: Humidity Sensor Mounting
1 Inside wall of cabinet
CAUTION!
Operating the Innova 43/43R at temperatures above 60ºC can result in
permanent damage to the sensor.
Water can be added to the spill pan in order to elevate the humidity level in the chamber.
See Section 6.9 for instructions.
6.9 Filling the Water Reservoir
If you choose to use the spill pan as a water reservoir to reduce evaporation and to raise
the humidity level in the chamber:
M1282-7012
