34
Innova 43 & 43R Incubator Shakers  M1320-0050 Operating manual
To modify a setpoint in this screen:
1. Use the Control Knob to highlight the current value (we will continue to use
the temperature as our example, so we will select 23 ).
2. Click the Knob in to display the current setpoint (in this example, 38.5 —see
Figure 15), which will flash.
Figure 15: Changing Setpoint
ºC 38.5
RPM 120
DISP We 13:44
3. Turn or spin the Knob to reset the setpoint (in this example, turn the Knob left
to decrease the setpoint to 37.0 ).
NOTE:
If you turn the Control Knob slowly, one click left or right will change the
setpoint by an increment of one tenth of a degree Celsius (0.1ºC). If you spin
the Knob, the value will change by larger increments.
4. Click the Knob in to set and save this new setpoint.
NOTE:
If you highlight an item, change it, but do not save your selection, after a few
seconds the screen will revert to its previous setting.
5. The display will automatically return to the actual value.
To move out of this screen and into the next:
1. Use the Control Knob to highlight
DISP , then click the Knob in. DISP begins
to flash.
2. Turn the Knob to the right until the next screen, Summary ( SUMM ), appears.
If you turn too far and enter another screen, just turn the Knob back to the left
to recapture the
SUMM screen.
3. Click the Knob in to select the screen and to work in it.
