28
Innova 43 & 43R Incubator Shakers  M1320-0050 Operating manual
Figure 12a: Humidity Monitor (optional)
1 Humidity monitor
When the humidity sensor is present in the chamber, maximum shaker temperature is
automatically limited to 60°C.
Specifications:
Humidity operating range: 0 to 100% RH Accuracy: See Figure 12b
Temperature operating range: 4 to 60ºC Hysteresis: ± 1.5% RH
Recovery time after saturation: 10 seconds Long term stability: 0.5% RH per year
Figure 12b: RH Sensor Operating Range & Humidity Error Graph
0
10
20
30
40
50
60
70
80
90
100
0 10 20 30 40 50 60
Temperature (C)
% R
H
+/- 5% Error
+/- 3% Error
+/- 5% Error INTERMITTENT
OPERATION
1
