18
Innova 43 & 43R Incubator Shakers  M1320-0050 Operating manual
Table 3: Display Icons
Icon Explanation
This icon appears when audible alarms are muted.
This icon appears when the possibility to make manual or
programmed parameter changes is disabled (locked). This is
controlled by settings on the SET screen. See Section 7.4.3
This icon appears when the shaker lid is open.
This icon appears when the Heater is on. See Section 5.10.
This icon appears when a user-defined Program is running. See
Section 7.5.5.
This icon appears to the right of ºC if the Temperature Offset
feature is being used. See Section 7.7.
5.5 Alarms
If an alarm condition exists, the field in the lower right corner will alternate the Day and
Time with characters indicating the nature of the alarm condition, accompanied by an
audible alarm (unless muted):
