33
New Brunswick Operating manual
Figure 13: Changing Display Parameter
ºC 23
RPM 120
DISP We 13:44
2. Click the Control Knob in. RPM will flash.
3. Turn the Knob until the desired parameter appears in the highlighted field.
For this example, we will select HRS .
4. Click the Knob in, to set and save the parameter (see Figure 14).
Figure 14: Changed Display Parameter
ºC 23
HRS 0.0
DISP We 13:44
You can also use this screen to verify a setpoint, even though the values displayed
here are actual (current) values. To view a setpoint:
1. Use the Control Knob to highlight the value (in this example, we will view the
temperature setpoint, so we will highlight the current ºC , which is 23 ).
2. Click the Knob in to display the current setpoint, which will flash.
At this point you can modify the setpoint or click the Knob in again to return to
the normal display, which will be the actual temperature.
