Main frame – SkyTrak 10054 User Manual
Page 7
3
SECTION 1
Item No.
Part Number
Qty.
Description
MAIN FRAME
1
Consult Factory
1
Weldment, Frame
2
7092292
8
Pin, Hoist, Slave, Tilt, and Stabilizer Cylinders
3
8303782
8
HHCS, 1/2-13 x 4"
4
8305644
8
Nut, Hex Lock Elastic 1/2-13
5
8065640
8
Bearing, 2" I.D.
’
6
6620531
AR
Conduit, 1 x 5' - Cut to Fit
7
8065641
2
Bearing, 2-3/4" I.D.
8
7124331
AR
Conduit, 1/2 x 5' - Cut to Fit
9
7125861
AR
Conduit, 3/4 x 5' - Cut to Fit
10
8520013
8
Fitting, Grease
11
8520021
2
Fitting, Grease 90°
12
8303724
8
HHCS, 3/4-10 x 3-1/2"
13
8310111
8
Washer, Flat .81 x 2 x .15"
14
8310067
8
Nut, Hex Lock Elastic 3/4-10
15
7079442
2
Pin, Axle Pivot
16
8307913
AR
Spacer, Washer .12" Thick
17
8307912
AR
Spacer, Washer .06" Thick
18
8310259
AR
Spacer, Washer .09" Thick
19
8303655
2
HHCS, 5/8-11 x 4-1/2"
20
8305643
2
Nut, Hex Lock Elastic 5/8-11
21
7099312
2
Anchor, Cylinder
22
8040258
2
Axle
23
7098563
1
Counterweight
24
8305021
4
Nut, Hex 1"-8
25
5724302
2
Washer, Shim .06" Thick
26
8307012
4
Washer, Lock 1"
27
8310066
2
Washer, Flat .134" Thick
28
8310051
4
HHCS, 1-8 x 4"
KITS
29
7138302
1
Kit, Cylinder Anchor (Includes 1 of Item 5, 1 of Item 10 and 1 of Item 21)
30
7129313
1
Kit, Hoist Cylinder Pivot Left Side (Includes 1 of Item 2, 1 of Item 5 and 1 of Item 10)
31
7129323
1
Kit, Hoist Cylinder Pivot Right Side (Includes 1 of Item 2, 1 of Item 5 and 1 of Item 10)
8042/10042/10054 Rev. 2/00
