SkyTrak 10054 User Manual
Page 327
333
SECTION 10
8042/10042/10054 Frame Tilt, Attachment Tilt, Slave &
Auxiliary Schematic
(S/N 9909 & After)
RESERVOIR
25
PSI
TEMP. SWITCH
195° F
500 / 600
PSI STANDBY
3000
PSI
PUMP
REAR AXLE VALVE
BRAKE VALVE
X
SHUTTLE
VALVE
0-45
GPM
PRESSURE
REDUCING
VALVE
PRESSURE
REDUCING
VALVE
PRIORITY
VALVE
STEERING
VALVE
2450-2550
PSI
STEERING
VALVE
X
TP
MAIN
CONTROL VALVE
OUTRIGGER
VALVE
FRAME TILT
CYLINDER
SLAVE
CYLINDER - L.H.
3200
PSI
SLAVE
CYLINDER - R.H.
3200 PSI
FRAME
TILT
VALVE
ATTACH.
TILT
VALVE
AUX.
VALVE
ATTACH. TILT
CYLINDER
AUX. QUICK
DISCONNECT COUPLERS
RELIEF VALVES OPTIONAL
REAR
AXLE
VALVE
3200 PSI
3200 PSI
LOW
PRESSURE
HIGH
PRESSURE
MH0640
Origin 2/00
