329
SECTION 10
8042/10042/10054 Frame Tilt, Attachment Tilt, Slave &
Auxiliary Schematic
(S/N 2194 & Before)
MAIN
CONTROL VALVE
OUTRIGGER
VALVE
FRAME TILT
CYLINDER
SLAVE
CYLINDER - L.H.
3200
PSI
SLAVE
CYLINDER - R.H.
3200 PSI
FRAME
TILT
VALVE
ATTACH.
TILT
VALVE
AUX.
VALVE
ATTACH. TILT
CYLINDER
AUX. QUICK
DISCONNECT COUPLERS
RELIEF VALVES OPTIONAL
REAR
AXLE
VALVE
.070 .070
TEMP.
SWITCH
210° F
RESERVOIR
25
PSI
SHUTTLE
VALVE
TEST
PORT
REAR AXLE VALVE
PRESSURE
REDUCING
VALVE
STEERING
VALVE
PRIORITY
VALVE
2450-2550
PSI
2900-3000
PSI
500-600
PSI
PUMP 46 GPM
3200 PSI
3200 PSI
STEERING
VALVE
PRESSURE
REDUCING
VALVE
LOW
PRESSURE
HIGH
PRESSURE
ORIFICE IN
FRAME TILT
VALVE FOR
S/N -267 &
AFTER
ORIFICES IN
FRAME TILT
CYLINDER
FOR S/N -266
& BEFORE
MH0321
Rev. 2/00
