SECTION 10
368
8042/10042
Stabil-TRAK System Troubleshooting
(S/N 9908 & Before)
Definitions:
PB = Park Brake
SB = Service Brake
DE = De-energized
E = Energized
C = Closed
O = Open
Reference page 370 & 371
Reference page 372 & 373
Reference page 374 & 375
Machine
Conditions
Switch/
Relay
Solenoid
Ignition On
Boom Below 40°
Trans. Fwd. or Rev.
Ignition On
Boom Above 40°
SB Released
Trans. Fwd. or Rev.
Ignition On
Boom Above 40°
PB & SB Applied
Trans. Neutral
Solenoid 1
E
DE
DE
Solenoid 2
E
DE
DE
Solenoid 3
DE
DE
E
Solenoid 4
DE
DE
E
Solenoid 5
DE
E
DE
Solenoid 6
DE
E
DE
Boom Angle Sensor
C
O
O
Boom Switch Relay
E
DE
DE
Stabilizer Lock Relay
DE
DE
E
Stabilizer Light
Off
Off
On
Origin 10/97
