SECTION 7
Item No.
Part Number
Qty.
Description
OUTRIGGER ELECTRICAL HARNESS
(10042/10054 Only)
1
7099923
1
Harness, Wiring (Includes Items 2 & 3) - (10042 Only)
7115114
1
Harness, Logic (Includes Items 2 & 3) - (10054 Only)
2
8220882
4
Connector, Solenoid (Includes Item 3)
3
8688026
4
Seal, Connector (Not Shown)
4
8223221
2
Switch, Toggle
5
7112592
1
Wire Assembly
6
7138469
1
Kit, Boom Sensor (S/N 9915 & Before)
7099882
1
Sensor, Boom (S/N 9916 & After)
7
7112582
1
Clip (S/N 9915 & Before)
7138468
1
Clip (S/N 9916 & After)
8
8303738
2
HHCS, 3/8-16 x 7/8"
9
8307005
2
Washer, Lock 3/8"
10
8310113
2
Nut, Cage 3/8-16
11
8225117
8
Relay
12
8229233
2
Fuse, 7.5 amp
13
8307111
2
Washer, Flat #10
14
8305002
2
Nut, Hex #10
15
8307003
2
Washer, Lock #10
16
8223525
2
Switch, Pressure
17
8307106
2
Washer, Flat 5/16 LT
KITS
18
7116632
1
Kit, Outrigger, Wire Harness
This kit is available to convert 10042 wire harness for use with circuit breakers
10042/10054 Rev. 2/00
