SECTION 6
Item No.
Part Number
Qty.
Description
BOOM HOIST CYLINDER
(S/N 5819 & After)
1
2714993
2
Cylinder, Boom Hoist (Includes Items 3 thru 18)
2
2713803
2
Cylinder, Boom Hoist w/Load Indicator Port (Includes Items 3 thru 18)
NOTE: Quantities Listed Below Are For 1 Cylinder Only
3
NSS
1
Tube, Cylinder (Serviced Only in Item 1)
NSS
1
Tube, Cylinder w/Load Indicator Port (Serviced Only in Item 2)
4
8035542
1
Valve, Counterbalance - present 4000 psi (See Kits)
5
8035308
1
Nut, Lock
6
See Kits
1
O-Ring
7
See Kits
1
Seal, Piston
8
8035545
1
Piston
9
8035608
1
Spacer, Rod
10
See Kits
1
O-Ring
11
See Kits
1
Ring, Backup
12
8035609
1
Gland
13
See Kits
1
Seal, Rod
14
See Kits
1
Wiper
15
8035607
1
Rod
16
See Kits
2
Wearband
17
See Kits
2
Wearband
18
8035610
1
Collar, Locking
KITS
19
8035386
1
Seal Kit, Boom Hoist Cylinder (Includes Items 6, 7, 10, 11, 13, 14, 16 & 17)
20
8205656
1
Seal Kit, Counterbalance Valve (Includes 3 O-Rings & 3 Back-Up Rings)
8042/10042/10054 Rev. 2/00
