SkyTrak 10054 - Manual (Page 186)

182
SECTION 6
SLAVE CYLINDER
(Current Production)
CURRENT PRODUCTION
VENDOR
STAMPING
EARLY PRODUCTION
IMPORTANT:
There are two similar but distinctly different Slave
Cylinders. Make sure you know which version you have
before ordering replacement parts. On “Early Production”
cylinders, the gland is installed flush with the cylinder
tube and has “TJB” stamped on the gland. On the
“Current Production” cylinders, the gland has a lip that
bottoms out against the cylinder tube.
PH2020
PF0760
1
2
3
4
5
6
7
8
9
11
12
13
14
16
17
18
16
10
7
16
13
16
14
12
15
9
17
11
8
Torque to
300 - 400 lb/ft
(407 - 542 Nm)
Apply Loctite #271
to threads. Torque
to 900 - 1050 lb/ft
(1220 - 1424 Nm).
Retract Port
Extend Port
15
8042/10042/10054 Origin 7/99
