SECTION 10
328
8042/10042/10054 Frame Tilt, Attachment Tilt, Slave &
Auxiliary Circuits
(S/N 2194 & Before)
LOAD SENSE (LS)
PILOT OPERATED CHECK VALVE LOCATIONS:
FRAME TILT CYLINDER - Rod & Base Sides
ATTACHMENT CYLINDER - Base Side
COUNTER BALANCE VALVE LOCATION:
ATTACHMET CYLINDER - Base Side
Park
Brake
OPERATOR'S CAB
T
SB
V
BRK P
AXLE
STABILIZER
VALVE
BLOCK
Attach
Tilt
Frame
Tilt
Aux.
Hyd.
SR
TC
T
TP C1
C2
PRESSURE
REDUCING
VALVE BLOCK
(Valve is bolted
to Axle Stabilizer
Valve Blocks)
P
T
LS
CONTROL
VALVE
Boom
Ext.
Boom
Hoist
P T
LS
LS
EF CF
T
P
PRIORITY
VALVE
SHUTTLE
VALVE
TRANSMISSION
MAIN
PUMP
LS
OUT
CONTROL
DRAIN
IN
Trans.
De-
Clutch
1
2
3
CONTROL
VALVE
FRAME TILT
CYLINDER
HYDRAULIC
RESERVOIR
FUEL
TANK
MAIN
FILTER
ATTACHMENT
TILT FORWARD
SLAVE
CYLINDER
SLAVE
CYLINDER
ATTACHMENT
TILT CYLINDER
AUXILIARY
HYDRAULICS
(optional)
MALE
FEMALE
ATTACHMENT
TILT BACK
MH0750
Origin 2/00
