145
SECTION 5
Item No. Part Number Qty. Description
ATTACHMENT TILT AND SLAVE CIRCUIT
1 8303752 2 HHCS, 5/16-18 x 3-1/2"
2 8307004 2 Washer, Lock 5/16"
3 8769149 1 Cover Plate, Single Clamp
4 8750003 4 Clamp, .62 Dia. Single (8042/10042 Only)
8750003 6 Clamp, .62 Dia. Single (10054 Only)
5 8769161 2 Clamp, .75 Dia. Single (8042/10042 Only)
6 2713452 2 Hose Assembly, Boom (8042/10042 Only)
7 8303739 3 HHCS, 5/16-18 x 1-1/4"
8 8769123 5 Cover Plate, Twin
9 8769122 3 Clamp, .62 Dia. Twin
10 7133823 1 Tube, Boom Attachment Tilt - Retract
11 7133833 1 Tube, Boom Attachment Tilt - Extend
12 8760037 2 Union, Bulkhead, Straight, SAE 10 - male JIC 37°
13 2713222 2 Hose, .50 I.D. x 34" Long
14 6605202 2 Hose, .50 I.D. x 44-1/2" Long
15 8760477 2 Tee, Bulkhead, Male Run, SAE 8 - male JIC 37°
16 6604982 2 Hose, .50 I.D. x 22" Long
17 8760493 2 Tee, Female Run, SAE 8 - male JIC 37° x female JIC 37° swivel
18 2712872 2 Hose, .50 I.D. x 153" Long
19 8760143 1 Connector, Long, SAE 8 - male JIC 37° x male str. thd. o-ring
20 8760107 7 Connector, Straight, SAE 8 - male JIC 37° x male str. thd. o-ring
(8042/10042 Only)
8760107 5 Connector, Straight, SAE 8 - male JIC 37° x male str. thd. o-ring
(10054 Only)
21 8760307 2 Elbow, 45° SAE 8 - male JIC 37° x male str. thd. o-ring (10054 Only)
22 7112452 1 Hose and Carrier Assembly (Includes Items 23 thru 25)
23 2713642 4 Hose Assembly
24 NSS 1 Carrier, Hose (For Service, Order Item 22)
25 8584001 2 Tie Wrap
26 8769140 1 Clamp Set, .675 twin
27 8305626 1 Nut, Hex Lock 5/16-18
28 8526048 AR Sealant
KITS
29 7117812 1 Kit, Hose Carrier Update
NOTE:
Kit Purpose:
To bring Early Production Hose Carrier (Item 24) up-to-date with solid bars in every other
link instead of in every link, with poly rollers added to bars, and with adhesive patch
coated screws instead of liquid sealant application.
8042/10042/10054 Rev. 2/00
