SECTION 10
8042/10042
Stabil-TRAK Electrical Circuit
Ignition “OFF”
(S/N 9908 & Before)
PARK
BRAKE
SWITCH
NEUTRAL
START
SWITCH
STARTER
SOLENOID
1
14
Fwd/Rev
NEU.
SWITCH
See NOTE
See
NOTE
O
NOTE:
7.5 Amp - S/N 292 & After
6.0 Amp - S/N 291 & Before
IGN. SWITCH
FUEL
SHUTOFF
SERVICE
BRAKE
SWITCH
BOOM
SWITCH
RELAY
BOOM UP
BOOM
DOWN
STABILIZER
LOCK
RELAY
SOL.
1
SOL.
2
SOL.
3
SOL.
4
SOL.
5
SOL.
6
STABILIZER
ENGAGED
LIGHT
PROXIMITY
SWITCH
45
10
39
47
40
48
2
28
40 Amp
35
41
42
DE
DE
DE
See NOTE
PARK
BRAKE/
DECLUTCH
SOLENOID
DE
DE
S/N 8042/10042-0291 & Before
Boom Switch Relay located in Kick Panel.
Stabilizer Lock Relay located under Dash to
the left side of the Steering Wheel
6.0 Amp Stabilizer Lock Relay
6.0 Amp Stabil-TRAK Relays &
Proximity Switch
6.0 Amp Park Brake Switch
40 Amp
Ignition Switch Feed
Boom
Switch
Relay
LEGEND
DE = De-energized
E = Energized
O = Open
PB = Park Brake
SB = Service Brake
S/N 8042/10042-0292 & After
Boom Switch and Stabilizer Lock
Relays located in Kick Panel
Boom
Switch
Relay
Stabilizer
Lock
Relay
7.5 Amp Steering Select Circuit
& Stabilizer Lock Relay
7.5 Amp Stabil-TRAK Solenoids,
Relay & Proximity Switch
7.5 Amp Warning Lights, Park Brake Switch,
Fuel Gauge & Hourmeter
40 Amp
Ignition Switch Feed
B
A
D
C
B
A
D
C
D
A
B
C
Stabilizer
Lock
Relay
SH0402
Rev. 2/00
