SkyTrak 10054 - Manual (Page 182)

178
SECTION 6
STABILIZER CYLINDER
1
2
3
13
14
15
4
5
6
16
17
7
8
9
10
11
12
Retract
Port
Extend
Port
Sol. 2
Sol. 6
Sol. 5
Sol. 1
Torque to
30 - 35 lb/ft
(41 - 48 Nm)
18
19
20
PH0351
PF0760
PF0760
PF0760
