Main control valve – SkyTrak 10054 User Manual
Page 203
199
SECTION 6
Item No.
Part Number
Qty.
Description
MAIN CONTROL VALVE
1
NLA
1
Main Control Valve (S/N 0224 & Before) For Service, Order Kit P/N 7115652
NLA
1
Main Control Valve (S/N 0225 thru 8540) For Service, Order P/N 8902186
8902186
1
Main Control Valve (Includes Items 2 thru 34) S/N 8541 & After
2
8034534
1
Section, Inlet (Includes 1 of Item 6)
3
7130912
1
Kit, Outlet Section (Includes Inlet & Outlet Sections and Mounting Hardware)
(S/N 2199 & Before)
8035267
1
Section - Outlet (S/N 2200 & After)
4
8034552
1
Section, Boom Extend (Includes Items 6 thru 18)
5
8034551
1
Section, Boom Hoist (Includes Items 6 thru 18)
6
8034697
1
O-Ring (See Kits)
7
See Kits
2
O-Ring
8
See Kits
2
Wiper
9
See Kits
2
Plate, Seal
10
See Kits
2
Screw, Rd. Hd. Mach.
11
See Kits
1
Poppet, C.V.
12
See Kits
1
Spring
13
See Kits
2
HHCS
14
See Kits
1
Cap, Spool
15
See Kits
1
End, Spool
16
See Kits
2
Seat, Spring
17
See Kits
1
Spring
18
See Kits
1
Shuttle
19
8034539
1
Plug, Shut-off
20
8034538
2
Relief Valve Assembly - Preset at 3200 ± 50 psi (Includes Items 21 thru 28)
21
See Kits
2
O-Ring
22
See Kits
1
Ring, Back-Up
23
See Kits
2
O-Ring
24
See Kits
1
O-Ring
25
See Kits
2
Ring, Back-Up
26
See Kits
1
Spring
27
See Kits
1
Spring
28
See Kits
1
Spring
29
See Kits
1
Tie Rod
30
See Kits
2
Nut, Special
31
See Kits
2
Tie Rod
32
See Kits
4
Nut, Special
33
8035387
1
Valve, Main Relief (Preset at 3500 ± 50 psi)
34
8760451
1
Plug, Hex Hd., SAE 6 - male str. thd. o-ring
KITS
35
8034541
AR
Rebuild Kit for Items 4 & 5
(Includes 3 of Item 6 and listed quantities of Items 7 thru 18)
36
8034540
1
Seal & Spring Kit for Relief Valve - Item 20
37
8903011
1
Tie Rod Kit - 2 Section Valve (Includes Items 29 thru 32)
38
7115652
1
Kit, Main Control Valve (Includes Valve and Instructions)
8042/10042/10054 Rev. 2/00
