SECTION 10
354
8042/10042/10054 Cranking Circuit
(S/N 9908 & Before)
RED/WHITE
STARTER
RELAY
RED
FUEL RUN
SOLENOID
RED/BLACK
DK. BLUE
FRAME
GROUND
NEUTRAL (N)
START SWITCH
40 AMP
RED
IGNITION
SWITCH
RED/BLACK
WHITE/
BLUE
WHITE
EMERGENCY
BRAKE
SWITCH
STARTER
BATTERY
CAB
FRAME
GROUND
5
2
1
4
3
RED
BLA
CK
27
34
34
19
37
29
2
29
27
2
BLACK
20
27
RED
26
1
14
WHITE/
BLUE
14
37
NOTE: 40 AMP Circuit
Breaker replaced with
40 AMP sealed fuse
S/N 8739 & After.
STARTER
BATTERY
CAB
FRAME
GROUND
19
S/N 0292 & Before
MH0221
Rev. 2/00
