159
SECTION 5
Item No. Part Number Qty. Description
AUXILIARY HYDRAULIC CIRCUIT
(Optional)
1 8310081 2 HHCS, 5/16-18 x 5"
2 8307004 2 Washer, Lock .31"
3 8307203 2 Washer, Flat 5/16" Heavy
4 7111402 1 Support, Clamp
5 8303679 2 HHCS, 3/8-16 x 1-3/4" (8042/10042 Only)
8303622 2 HHCS, 3/8-16 x 2" (10054 Only)
6 8769161 2 Clamp, Single .75 I.D. (8042/10042 Only)
8750003 2 Clamp, Single .62 I.D. (10054 Only)
7 2713082 2 Hose, .50 I.D. x 426" Long (8042/10042 Only)
8 8769122 3 Clamp, Twin .62 I.D. (Two Halves)
9 8303757 3 HHCS, 5/16-18 x 2-1/2"
10 7133843 1 Tube Assembly
11 7133853 1 Tube Assembly
12 8760037 2 Union, Bulkhead, Straight, SAE 10 - male JIC 37°
13 2713212 2 Hose, .50 I.D. x 30" Long
14 8760264 2 Elbow, 90°, Bulkhead, SAE 8 - male JIC 37°
15 2712872 2 Hose, .50 I.D. x 153" Long
16 8760107 1 Connector, Straight, SAE 8 - male JIC 37° x male str. thd. o-ring
17 8760143 1 Connector, Long, SAE 8 - male JIC 37° x male str. thd. o-ring
18 8420055 1 Plug, Dust #8
19 8420053 1 Cap, Dust #8
20 8430006 1 Quick Disconnect, Male, SAE 8-8ORB - female internal (Includes Item 21)
21 8640029 1 Seal, Nose (Not Shown)
22 8430005 1 Quick Disconnect, Female, SAE 8-8ORB - female internal (Includes Items 23 thru 25)
23 8640029 1 Seal, Nose (Not Shown)
24 8640028 1 Seal, Coupler Body (Not Shown)
25 8640032 1 Back-Up Ring, Coupler Body Seal (Not Shown)
26 8760142 2 Connector, Straight, SAE 8-8 - male str. thd. o-ring x female JIC 37° swivel
27 8760045 2 Union, Bulkhead, Straight, SAE 8 - male JIC 37°
28 7112452 1 Hose and Carrier Assembly (Includes Items 29 thru 31)
29 NSS 1 Carrier, Hose (For Service, Order Item 28)
30 8584001 2 Tie Wrap
31 2713642 4 Hose Assembly
KITS
32 7117812 1 Kit, Hose Carrier Update
NOTE:
Kit Purpose:
To bring Early Production Hose Carrier (Item 29) up-to-date with solid bars in every other
link instead of in every link, with poly rollers added to bars, and with adhesive patch
coated screws instead of liquid sealant application.
8042/10042/10054 Rev. 2/00
