SECTION 10
340
8042/10042/10054 Service Brake Circuit
(S/N 9909 & After)
OPERATOR'S CAB
BRK
P
BRAKE
VALVE
T C1
C2
HYDRAULIC
RESERVOIR
Boom
Ext.
Boom
Hoist
FUEL
TANK
P
T
LS
EF CF
T
P
MAIN
FILTER
PRIORITY
VALVE
CONTROL
VALVE
PRESSURE
REDUCING
VALVE
PRESSURE
REDUCING
VALVE
BLOCK
(Valve is
bolted to
Axle Stabilizer
Valve Block)
RIGHT
FRONT
BRAKE
LEFT
FRONT
BRAKE
LEFT
REAR
BRAKE
RIGHT
REAR
BRAKE
MAIN
PUMP
TRANSMISSION
CONTROL
DRAIN
LS
OUT
IN
PARK
BRAKE
MH0610
Origin 2/00
