130
SECTION 4
FUEL SYSTEM (EPA)
(S/N 1599 & After)
Engine Is Turned Around 180°
From Mounted Position
For Clarity
Fuel
Return
Fuel
Supply
1
2
3
4
5
6
7
8
9 10 11
10
10
12
20
14 13
21
10
20
14
13
15
16
17
19
18
PH0032
8042/10042/10054 Rev. 2/00
