Axle wheel ends, S/n 0461 & after) – SkyTrak 10054 User Manual
Page 113
109
SECTION 3
Item No.
Part Number
Qty.
Description
AXLE WHEEL ENDS
(S/N 0461 & After)
NOTE: Quantities are for one wheel end assembly unless otherwise specified.
1
8034814
1
Wheel End Assembly, Front & Rear (Includes Items 2 thru 45)
2
8032906
18
Screw, Hex Hd, Self Locking
3
8033012
1
Planetary Gear Assembly (Includes Items 4 thru 14)
4
8032903
1
Flange, Planetary Drive
5
8032895
1
Plug, Pipe
6
8032894
1
Plug, Hex Hd
7
8032900
3
Pin, Roll
8
8032899
3
Shaft, Planet Gear
9
8032896
1
Washer, Drive Flange
10
8032901
6
Washer, Keyed
11
8032898
150
Bearing, Single Roller
12
8032897
3
Washer, Planet Gear
13
8032902
3
Gear, Spur
14
8032904
1
Plate, Lining Stop
15
8033826
1
Ring, Snap
16
8033827
1
Gear, Spur
17
NSS
4
Plate, Lining Stop (See Kits)
18
NSS
4
Disc Assembly (See Kits)
19
8032912
1
Piston
20
8034692
1
O-Ring (See Kits)
21
8034693
1
O-Ring (See Kits)
22
8032922
2
O-Ring (See Kits)
23
8032923
1
O-Ring (See Kits)
24
See Kits
1
Spindle Assembly (Includes Items 25 & 26)
25
8033828
1
Bushing, Spindle
26
8032826
2
Seat, Insert
27
8034584
6
Screw, 12 Point Cap - 1/2"
28
8034585
6
Washer, Flat Hardened 1/2"
29
8032984
1
Plug, Bleeder
30
8032985
1
O-Ring, Bleeder Plug
31
8033829
1
Fitting, Brake
32
8033803
1
Seal, Oil - Spindle (See Kits Page 103)
33
8034586
1
Retainer, Bearing Adjusting Ring (Includes Item 34)
34
8032949
1
Tubing, Brake
35
8032972
AR
Shim, Adjusting (.010")
8035268
AR
Shim, Adjusting (.011")
8035269
AR
Shim, Adjusting (.012")
8035270
AR
Shim, Adjusting (.013")
8035271
AR
Shim, Adjusting (.014")
8035272
AR
Shim, Adjusting (.015")
8032973
AR
Shim, Adjusting (.020")
8032974
AR
Shim, Adjusting (.030")
36
8032910
1
Gear, Planetary Ring
37
8032913
1
Cone, Roller
38
8033831
1
Hub Assembly (Includes Items 39 thru 42)
39
8033832
1
Hub, Planetary
40
8032891
1
Cup, Roller Bearing
41
8032892
1
Cup, Roller Bearing
42
8032893
10
Bolt, Wheel, Right Side
43
8786516
10
Nut, Wheel
44
8032914
1
Cone, Roller Bearing
45
8032983
1
Seal, Oil - Wheel Hub (See Kits Page 103)
46
8522043
1
Friction Modifier Fluid (Low Odor) 32 Oz. (enough to service 4 wheel ends)
47
8522045
1
Wheel End Oil 2-1/2 Gal. (enough to service 4 wheel ends)
48
8522048
1
Wheel End Oil 1 Gal.
KITS
49
8034688
1
Brake Kit (Includes Items 17 & 18) (this kit services one wheel end)
50
8034819
1
Wet Brake Seal Kit (Includes Items 20 thru 23)
51
8034590
1
Service Kit, Spindle (Includes Items 24 thru 27)
8042/10042/10054 Rev. 2/00
