10054 Hoist and Extend Schematic
(S/N 9909 & After)
RESERVOIR
25
PSI
TEMP. SWITCH
195° F
500 / 600
PSI STANDBY
3000
PSI
PUMP
REAR AXLE VALVE
BRAKE VALVE
TP
SHUTTLE
VALVE
0-45
GPM
PRESSURE
REDUCING
VALVE
PRESSURE
REDUCING
VALVE
PRIORITY
VALVE
STEERING
VALVE
2450-2550
PSI
STEERING
VALVE
X
X
X
OUTRIGGER
VALVE
HOIST
CYLINDER - L.H.
HOIST
CYLINDER - R.H.
3200
PSI
MAIN
CONTROL
VALVE
EXTEND
CYLINDER
3200
PSI
HOIST
VALVE
EXTEND
RETRACT
VALVE
HIGH
PRESSURE
HIGH
PRESSURE
LOW
PRESSURE
LOW
PRESSURE
LOW
PRESSURE
HIGH
PRESSURE
HIGH
PRESSURE
LOW
PRESSURE
