SECTION 10
374
8042/10042
Stabil-TRAK Electrical Circuit
Locked Mode
(S/N 9908 & Before) 1. Ignition “ON” 4. SB & PB Applied
2. Transmission in Neutral 5.
3. Boom Above 40° 6.
NOTE:
7.5 Amp - S/N 292 & After
6.0 Amp - S/N 291 & Before
S/N 8042/10042-0292 & After
Boom Switch and Stabilizer Lock
Relays located in Kick Panel
S/N 8042/10042-0291 & Before
Boom Switch Relay located in Kick Panel.
Stabilizer Lock Relay located under Dash to
the left side of the Steering Wheel
IGN. SWITCH
FUEL
SHUTOFF
PARK
BRAKE
SWITCH
NEUTRAL
START
SWITCH
STARTER
SOLENOID
PARK
BRAKE/
DECLUTCH
SOLENOID
Fwd/Rev
NEU.
SWITCH
SERVICE
BRAKE
SWITCH
BOOM
SWITCH
RELAY
BOOM UP
BOOM
DOWN
STABILIZER
LOCK
RELAY
SOL.
1
SOL.
2 SOL.
3
SOL.
4
SOL.
5
SOL.
6
STABILIZER
ENGAGED
LIGHT
PROXIMITY
SWITCH
45
10
39
47
40
48
2
28
35
1
14
41
40 Amp See NOTE
DE
E
DE
DE
O
See NOTE
See
NOTE
LEGEND
DE = De-energized
E = Energized
O = Open
PB = Park Brake
SB = Service Brake
Boom
Switch
Relay
Stabilizer
Lock
Relay
7.5 Amp Steering Select Circuit
& Stabilizer Lock Relay
7.5 Amp Stabil-TRAK Solenoids,
Relay & Proximity Switch
7.5 Amp Warning Lights, Park Brake Switch,
Fuel Gauge & Hourmeter
40 Amp Ignition Switch Feed
6.0 Amp Stabilizer Lock Relay
6.0 Amp Stabil-TRAK Relays &
Proximity Switch
6.0 Amp Park Brake Switch
40 Amp Ignition Switch Feed
Boom
Switch
Relay
Stabilizer
Lock
Relay
42
B
A
D
C
B
A
D
C
D
A
B
C
SH0541
Rev. 2/00
