Page 170
166
SECTION 6
MAIN PUMP
(S/N 9909 & After)
PH1221
1
2*
3* 4
5
6
7* 8
9*
10*
11
12
13
14
15
16
17*
18
19 20
21
22 23
24
25
26
27 28
29 30
31
32 33
34
35
36
37
38 39
40 41
42
4
59
61
60*
56*
17*
18
43 44
45 46
53
58*
47*
48
49 50 51
52
54
55*
57
PF0760
63
64
65
66
67
68
69
14
*Item
Torque values
2
13.3-17.8 lb/ft (18-24 Nm)
3
192.4-222 lb/ft (280-300 Nm)
7
21.5-23.7 lb/ft (29-32 Nm)
9
76.2-94 lb/ft (103-127 Nm)
10
76.2-94 lb/ft (103-127 Nm)
17
55.5-61.4 lb/ft (75-83 Nm)
47
2.7-3.3 lb/ft (3-4 Nm)
55
76.2-94 lb/ft (103-127 Nm)
56
23-27.4 lb/ft (31-37 Nm)
58
9.6-11 lb/ft (13-15 Nm)
60
11.1-11.8 lb/ft (15-16 Nm)
62
8042/10042/10054 Origin 7/99
