SkyTrak 10054 User Manual
Page 349
355
SECTION 10
8042/10042/10054 Cranking Circuit
(S/N 9909 & After)
RED/WHITE
STARTER
RELAY
RED
FUEL RUN
SOLENOID
RED/BLACK
FRAME
GROUND
NEUTRAL (N)
START RELAY
40 AMP
RED
IGNITION
SWITCH
RED/BLACK
WHITE
EMERGENCY
BRAKE
SWITCH
STARTER
BATTERY
CAB
FRAME
GROUND
5
2
1
4
3
RED
BLA
CK
27
34
34
19
106
29
2
29
27
2
BLACK
20
27
RED
26
1
30A
RED/WHITE
100
TO
SHIFTER
106
BLUE/ORANGE
111
RED
GREY
114
MH0700
Origin 2/00
