190
SECTION 6
SWING CARRIAGE CYLINDER
1
2
3
10
11
12
4
5
6
13
14
17
7
8
9
Retract
Port
“X”
Port
Extend
Port
Torque to
30 - 35 lb/ft
(41 - 48 Nm)
Apply Loctite
#271 to Inside
Threads
15
16
PH0441
PF0760
PF0760
PF0760
Torque to
250 lb/ft
(339 Nm)
Torque to
30 - 35 lb/ft
(41 - 48 Nm)
8042/10042/10054 Rev. 2/00
