325
SECTION 10
10054 Hoist and Extend Schematic
(S/N 8541 thru 9908)
X
X
TEMP.
SWITCH
210° F
RESERVOIR
25
PSI
SHUTTLE
VALVE TEST
PORT
REAR AXLE VALVE
PRESSURE
REDUCING VALVE
PRESSURE
REDUCING
VALVE
STEERING
VALVE
OUTRIGGER
VALVE
PRIORITY
VALVE
2450-2550
PSI
2900-3000
PSI
500-600
PSI
PUMP 46 GPM
HOIST
CYLINDER - L.H.
HOIST
CYLINDER - R.H.
3200
PSI
MAIN
CONTROL
VALVE
EXTEND
CYLINDER
3200
PSI
HOIST
VALVE
EXTEND
RETRACT
VALVE
STEERING
VALVE
HIGH
PRESSURE
HIGH
PRESSURE
LOW
PRESSURE
LOW
PRESSURE
LOW
PRESSURE
HIGH
PRESSURE
HIGH
PRESSURE
LOW
PRESSURE
MH0620
Rev. 2/00
