68 TLS2200
T M
Thermal Transfer Printer User’s Guide
T17: Creating a Legend List, Banner Legends
Note: This example assumes you have the banner marker roll PTL-42-439OR
loaded in your printer.
Setup Status:
H Justify Center
V Justify Center
Rotation 0 Degrees
Format Component
Legend Type Text
1.
Press .
2. Press the <
?> key once to select Create, then press .
3. When “Enter List Name” prompt appears, enter LIST6, then press
.
4. When “Enter Part No.” prompt appears, enter PTL-42-439, then press
.
5. Press +
6. Press + to access the Setup Menu.
7. Press the <
?
> key six times to select Units, then press .
8. Press the <
>
> or <
?
> keys to toggle the Units to Metric, then press
.
9. Press the <
>
> key four times to select Continuous, then press
.
10. With the cursor highlighted on Banner, press .
11. Press + to exit back to the Text Editor screen.
12. Enter 120 VOLTS on line one.
13. Press +.
14. Press +.
120 VOLTS CAUTION COMMUNICATIONS CLOSET
