52 TLS2200
T M
Thermal Transfer Printer User’s Guide
T8: Creating a Terminal Block Label
Note: This example assumes you have the terminal block marker roll PTLTB-400-
375 loaded in your printer.
Label to be printed:
101
102
103
104
105
106
107
108
109
110
Setup Status:
H Justify Center
V Justify Center
Rotation 0 Degrees
Format Component
Legend Type Text
1.
Press +
2. Press + to access the Setup Menu.
3. Press the <
?
> key six times to select Units, then press .
4. Press the <
>
> or <
?
> keys to toggle the Units to Metric, then press .
5. Press the <
>
> key four times to select Continuous, then press .
6. With the cursor highlighted on Terminal Block, press .
7. Use the <
>
> and <
?
> keys as needed to set the terminal block repeat value to 6 mm
(.23622 in.), then press .
