Thermal Transfer Printer User’s Guide
Continuous
The Continuous Menu contains the following user options:
Option Description
Terminal
Block Adjusts the terminal block repeat value. Setting ranges from 5 mm
(0.19685 in) to 46 mm (1.81102 in). <
>
> and <
?
> keys
increase/decrease value by 0.125 mm increments (1 dot). +
<
>
> and + <
?
> increase/ decrease value by 1mm increments (8
dots).
Banner Sets the orientation of the legend text on the banner. Toggles between
vertical and horizontal.
Fixed Length Adjusts the maximum length of the banner. Setting ranges from 32 mm
(1.02362 in) to 305 mm (12.28346 in). <
>
> and <
?
> keys
increase/decrease value by 13 mm (.51 in) increments. + <
>
>
and + <
?
> increase/ decrease value by 26 mm (1.02 in)
increments.
Style
The Style Menu contains the following user options:
Option Description
Rotation Sets the rotation in one of four orientations. 0
Ε
, 90
Ε
, 180
Ε
, and 270
Ε
.
Default orientation is dependent on the marker roll loaded in the unit.
Always select the rotation value before entering the text for your label. A
change to the rotation value causes the following to occur:
•
All characters and lines on a legend are deleted.
•
The cursor moves to the first character position on line one.
•
The font is set to the default size for the marker.
Note: Rotation option is not supported for BradySleeve, PermaSleeve, and
pre-printed marker parts (defaults to 0
Ε
).
H Justify Sets the horizontal justification of the legend. Options are: Left, Center, and
Right. The marker roll loaded in the unit determines the default setting.
V Justify Sets the vertical justification of the legend. Options are: Top, Center, and
Bottom. The marker roll loaded in the unit determines the default setting.
