Class1 FoamLogix 2.1A & 1.7AHP REV D - Manual (Page 18)

FoamLogix, Model 2.1A and 1.7AHP Class “A”
Electronic Foam Proportioning Systems
18
HALE FOAM SYSTEM SPECIFICATIONS
2.1A 1.7AHP
Foam Pump Dual Plunger Dual Plunger
Maximum Foam Concentrate Output 2.1 GPM (8 LPM) 1.7 GPM (6.5 LPM)
Maximum System Operating Pressure 250 PSI (17 BAR) 400 PSI (27.5 BAR)
Maximum Operating Temperature 160 o F (71 o C) 160 o F (71 o C)
Pump Motor 0.44 HP (0.3 Kw), 12 VDC 0.44 HP (0.3 Kw), 12
VDC
Operating Ampere Draw 25 AMPS @ 12 VDC 30 AMPS @ 12 VDC
Maximum Ampere Draw 40 AMPS @ 12 VDC 40 AMPS @ 12 VDC
