Xerox WorkCentre M20-M20i-2723 - Manual (Page 31)

Xerox WorkCentre M20i System Administration Guide Page 2-5
Bas
ic Netw
ork Ins
tallation
Basic TCP/IP Settings
Before the printer can be used on the network, the TCP/IP addresses need to be entered.
These can be entered automatically using Dynamic Host Configuration Protocol (DHCP) or
Bootstrap Protocol (BOOTP) or entered manually. To enter the addresses manually, you need
to obtain the following:
¾ TCP/IP Address
¾ Gateway Address
¾ Subnet Mask Address
¾ Primary DNS Server Address
Installation Procedure
There are three stages required to install the WorkCentre M20i in a TCP/IP networking
environment:
¾ Network Communication Setup
This requires the WorkCentre M20i to be setup for TCP/IP.
¾ Workstation Setup
This requires the Workstations in the networking environment to be
configured to communicate with the WorkCentre M20i.
¾ Test Print
A print job should be submitted to ensure the WorkCentre M20i has been
installed and configured correctly.
